ASRock NUC BOX 8265U [30/36] English
![ASRock NUC BOX 8265U [30/36] English](/views2/1693786/page30/bg1e.png)
NUC BOX 8265U/8365UE
24 25
English
5.2 Motherboard Specications
Form
Factor
Dimensions NUC 4.09" x 4.02" (104 x 102mm)
Processor
System
CPU
Intel
®
8th Gen (Whiskey lake-U) Core™ MCP
Processors
I5-8365UE QC, 1.6GHz, 15 W (NUC-8365UE)
Chipset
SoC
Expansion
Slot
PCIe N/A
Mini-PCIe N/A
mSATA N/A
M.2
1 x Key M (2242/2260/2280 by BRACKET) with
PCIe x4 and SATA3 for SSD
1 x Key E (2230) with PCIe x1 and USB 2.0 for
Wireless
Memory
Technology Dual Channel DDR4 2400 MHz
Max. 32GB
Socket 2 x SO-DIMM
Graphics
Controller N/A
DVI N/A
LVDS N/A
HDMI
HDMI 1 : Supports max resolution up to
4Kx2K@30Hz
DisplayPort
Supports max resolution up to 3840 x
2160@60Hz
Multi Display Triple Display
eDP N/A
Ethernet
Ethernet 10/100/1000 Mbps
Controller 1 x Intel
®
I219LM, 1 x Realtek RTL8111G)
Rear I/O
VGA N/A
DVI N/A
HDMI 1
DisplayPort 2
Ethernet 2
USB 3 x USB 3.1
Audio 1 (Mic-in, Line-out)
Serial N/A
eSATA N/A
PS2 N/A
