ASRock NUC BOX 8265U [7/36] Product specifications
![ASRock NUC BOX 8265U [7/36] Product specifications](/views2/1693786/page7/bg7.png)
NUC BOX 8265U/8365UE
PB 2
English
1.2 Product Specications
NUC BOX
8265U/8365UE
Barebone
CPU
Intel® 8
th
Gen (Whiskey lake-U) Core™ MCP Processors
NUC BOX 8265U (I5-8265U QC, 1.6HGz, 15W)
NUC BOX 8365UE (I5-8365UE QC, 1.6GHz, 15 W)
OS
N/A
Chipset
SoC
Memory
Supports Dual Channel DDR4 2400 MHz, 2 x SO-DIMM slots,
Max. 32GB
HDD
N/A
Optional
Supports 1 x 2.5" SATA HDD*/SSD
LAN
Gigabit LAN
WiFi
Optional
Audio
Realtek ALC233
Front I/O
1 x USB 3.1(Type A), 2 x USB 2.0 (Type A), 1 x Audio-out with
MIC-In
Rear I/O
2 x USB 3.0 (Type A), 1 x HDMI, 2 x DP, 2 x LAN, DC-IN,
1 x Kensington lock
Power Unit
96W Adapter
eMMC
M.2
slot
2.5”HDD
