NMI (Nonmaskable Interrupt) Button
Press the NMI button with a paper clip or pin to generate a nonmaskable interrupt and to
put the server in a halt state for examination.
System Reset Button
When the system is completely unresponsive, press the system reset button to reboot the
server without shutting it o and initialize the system.
Status LED Denitions
Power LED
Status Description
Green Power on
O Power o
ID LED
Status Description
Blue System identication is active.
O System identication is disabled.
LAN1, LAN2, LAN3, LAN4 LEDs
Status Description
Green Link between system and network or no access
Blinking Green Network access
HDD Activity LED
Status Description
Blinking Green HDD access
O HDD idle
System Event LED
Status Description
O Running or normal operation
Red At least one sensor has critical alert
