ASRock 3U8G-C612 [17/59] Fan failed led
![ASRock 3U8G-C612 [17/59] Fan failed led](/views2/1694132/page17/bg11.png)
12 13
English
HDD Activity LED
Status Description
Solid Green HDD active
Blinking Green HDD accessing or reading
Red HDD failed
O HDD powered-o
2.8 Fan Failed LED
Fan Failed LED
Fan LED
Status Description
Solid Red Fan failed
O Normal
