ASRock 3U8G-C612 [57/59] English
![ASRock 3U8G-C612 [57/59] English](/views2/1694132/page57/bg39.png)
52 53
English
Sliding the Server into the Rack
1. Ensure that the slide rails are properly and securely attached to the rack.
2. Fully extend the slide rails from the rack by pulling the inner rails out until they are
locked and cannot be pulled out further.
11U
12U
To slide an inner rail back into the slide rail, press the metal tab on the inner rail, and
simultaneously slide the inner rail into the slide rail .
