1.2 Specications
3U8G Series
System Physical Status
Form Factor 3U Rackmount
Dimension
(D x W x H)
27.9" x 16.9" x 5.1" (711.2 x 430 x 130.35 mm)
Support MB Size CEB
Front Panel
Buttons • Power On/Standby button
• ID button*
• System reset button
• NMI button*
LEDs • Power LED
• Identication LED*
• Hard drive activity LED*
• 4 x Network activity LEDs*
• System event LED*
I/O Ports 2 x USB 2.0 ports
Drive Bay
External 6 x 2.5" SATA HDDs (6Gb/s)*
System Cooling
Fan 8 x 80*38 mm system fans
Power Supply
Capacity 4 (3+1), Redundant
Output Watts 10 00W @ 90Vac~132Vac
1200W @ 200Vac~264Vac
System Switch Board
Switch IC PLX 8747
GPGPU Card
GPGPU Watts Max 300w /per card
Support GPGPU 8 x GPGPU cards
*Please be noted that the functions are supported depending on the type of the server board.
Please refer to the user manual of the motherboard you use for detailed information about
motherboard components and features.
