Biostar B360GT5S Версия 5.x [4/44] 3 specifications
![Biostar B360GT5S Версия 5.x [4/44] 3 specifications](/views2/1707914/page4/bg4.png)
4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Socket 1151 for 8th Intel® Core i7 / i5 / i3 / Penum / Celeron processor
Maximum CPU TDP (Thermal Design Power): 95Wa
* Please refer to www.biostar.com.tw for CPU support list.
Chipset INTEL® B360
Memory
Supports Dual Channel DDR4 2666/ 2400/ 2133/ 1866
4x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory
Each DIMM supports non-ECC 4/8/16GB DDR4 module
* Please refer to www.biostar.com.tw for Memory support list.
Storage
6x SATA III (6Gb/s) : Supports AHCI
1x M.2 - 32Gb/s (PCIE-M2_1) :
Supports M.2 Type 2242/ 2260/ 2280/ 22110 SSD module
Supports PCI-E SSD, Intel® Optane Technology
1x M.2 - 16Gb/s (PCIE-M2_2) :
Supports M.2 Type 2242/ 2260/ 2280 SSD module
Supports PCI-E & SATA SSD
1x PCIe 3.0 x16 (@x4) slot (Share bandwidth with PCIE-M2_1 slot):
Supports PCI-E SSD, Intel® Optane Technology
* When using SATA SSD module on PCIE-M2_2 slot, the SATA3_1 connector will be disabled.
LAN
Intel i219V
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC1150
7.1 Channels, High Denion Audio, Hi-Fi(Front)
USB
1x USB 3.1(Gen2) Type-C port (1 on rear I/O)
1x USB 3.1(Gen2) port (1 on rear I/O)
4x USB 3.1(Gen1) port (2 on rear I/Os and 2 via internal headers)
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
Expansion Slots
3x PCIe 3.0 x1 Slot
1x PCIe 3.0 x16 Slot (x4)
1x PCIe 3.0 x16 Slot (x4): Supports Intel® Optane Technology
1x PCIe 3.0 x16 Slot (x16)
* PEX16_SB_1 run in x2 speed when PEX1_SB_2 or PEX1_SB_3 is occupied.
Rear I/Os
1x PS/2 Keyboard/ Mouse Port
1x VGA Port
1x DVI-D Port
1x HDMI Port
1x USB 3.1(Gen2) Type-C Port
1x USB 3.1(Gen2) Port
2x USB 3.1(Gen1) Port
2x USB 2.0 Port
1x LAN port
6x Audio Jack
Internal I/Os
6x SATA III Connector (6Gb/s)
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x USB 3.1(Gen1) Header (each header supports 2 USB 3.1(Gen1) ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
3x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x S/PDIF out Connector
2x 5050 LED Header
Form Factor ATX Form Factor, 234 mm x 304.8 mm
OS Support
Windows 10(64bit)
* Biostar reserves the right to add or remove support for any OS with or without noce.
