APPENDIX I: Specicaons in Other Languages | 43
B360GT5S
Spanish
Especicaciones
Compabilidad con el
procesador
Ranura 1151 para el 8º procesador Intel® Core i7 / i5 / i3 / Penum / Celeron
Alimentación de Proyección Térmica (TDP – Thermal Design Power): 95Wa
*Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el procesador.
Tipo de Placa INTEL® B360
Memoria
Soporta DDR4 2666/2400/2133/1866(OC) Doble Canal
4x DDR4 DIMM Ranura de memoria Soporta hasta 64 GB Memoria
Cada DIMM soporta un modulo non-ECC 4/8/16 GB DDR4
*Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el memoria.
Almacenamiento de
información
Conector 6x SATA III (6Gb/s) : Soporta AHCI
1x M.2 - 32Gb/s (PCIE-M2_1):
Soporta módulo M.2 po 2242/ 2260/ 2280/ 22110 SSD
Soporta PCI-E SSD, Intel® Optane Technology
1x M.2 - 16Gb/s (PCIE-M2_2):
Soporta módulo M.2 po 2242/ 2260/ 2280 SSD
Soporta PCI-E & SATA SSD
1x PCIe 3.0 x16 (@x4) :
Soporta PCI-E SSD, Intel® Optane Technology
LAN
Intel i219V
10/ 100/ 1000 Mb/s auto negociación, capacidad dúplex Mitad/Completo
Códec Audio
ALC1150
Canales Audio de Alta Denición 7.1, Hi-Fi(Front)
USB
Ranura 1x USB 3.1(Gen2) TYPE-C (1 en las entrada/salidas posteriores)
Ranura 1x USB 3.1(Gen2) (1 en las entrada/salidas posteriores)
Ranura 4x USB 3.1(Gen1) (2 en las entrada/salidas posteriores y 2 por los distribuidores internos)
Ranura 6x USB 2.0 (2 en las entrada/salidas posteriores y 4 por los distribuidores internos)
Ranuras de Exnción
Ranura 3x PCIe 3.0 x1
Ranura 1x PCIe 3.0 x16 (x4)
Ranura 1x PCIe 3.0 x16 (x4): Soporta Intel® Optane Technology
Ranura 1x PCIe 3.0 x16 (x16)
Panel trasero de E/S
Teclado / Ratón 1x PS/2
Ranura 1x VGA
Ranura 1x DVI-D
Ranura 1x HDMI
Ranura 1x USB 3.1(Gen2) TYPE-C
Ranura 1x USB 3.1(Gen2)
Ranura 2x USB 3.1(Gen1)
Ranura 2x USB 2.0
Ranura 1x LAN
Socket audio 6x
Conectores en placa
Conector 6x SATA III (6Gb/s)
Distribuidor 2x USB 2.0 (cada distribuidor soporta 2 ranuras USB 2.0)
Distribuidor 1x 3.1(Gen1) (cada distribuidor soporta 2 ranuras USB 3.1(Gen1))
Conector con 8 pallas x1
Conector con 24 pallas x1
Conector Venlador procesador x1
Conector Venlador Sistema x3
Distribuidor Panel Frontal x1
Distribuidor Audio Frontal x1
Distribuidor CMOS Directo x1
Conector Externo S/PDIF x1
Distribuidor 5050 LED x2
Factor de Forma Factor de Forma ATX, 234 mm x 304.8 mm
Soporte OS
Windows 10(64bit)
* Biostar reserva su derecho de añadir o rerar el soporte para cada OS con o sin nocación.
