Biostar B365GTQ Версия 5.X [4/87] 3 specifications
![Biostar B365GTQ Версия 5.X [4/87] 3 specifications](/views2/1707916/page4/bg4.png)
4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Socket 1151 for 9th / 8th Gen Intel® Core, Penum and Celeron processors
Maximum CPU TDP (Thermal Design Power): 95Wa
* 9th / 8th Generaon Intel® Core™ Processor Family only support 300-Series.
* Please refer to www.biostar.com.tw for CPU support list.
Chipset INTEL® B365
Memory
Supports Dual Channel DDR4 1866/2133/2400/2666
4x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory
Each DIMM supports non-ECC 4/8/16GB DDR4 module
* Please refer to www.biostar.com.tw for Memory support list.
Storage
4x SATA III Connector (6Gb/s)
1x M.2 (M Key) :
Supports PCI-E 3.0 x4 (32Gb/s) & SATA III (6Gb/s) SSD
Supports PCIe RAID 0, 1, 5, 10 / Intel® Rapid Storage Technology & Intel® Optane Technology
LAN
RTL8111H
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC887
7.1 Channels, High Denion Audio
USB
6x USB 3.1(Gen1) port (4 on rear I/Os and 2 via internal header)
6x USB 2.0 port (2 on rear I/Os and 4 via internal header)
Expansion Slots
2x PCIe 3.0 x1 Slot
1x PCIe 3.0 x16 Slot
Rear I/Os
1x PS/2 Keyboard Port
1x HDMI Port
1x VGA Port
1x LAN Port
2x USB 2.0 Port
4x USB 3.1(Gen1) Port
3x Audio Jack
Internal I/Os
4x SATA III Connector (6Gb/s)
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x USB 3.1(Gen1) Header (each header supports 2 USB 3.1(Gen1) ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
2x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x COM Port Header
2x LED Header (12V/ 5V)
Form Factor uATX Form Factor, 244mm x 210mm
OS Support
Windows 10(64bit)
* Biostar reserves the right to add or remove support for any OS with or without noce.
