第一章: 主板介绍 | 3
Hi-Fi H170S3H / Hi-Fi B150S3H
第一章: 主板介绍
1�1 前言
感谢您选购我们的产品，在开始安装主板前，请仔细阅读以下安全指导说明：
• 选择清洁稳定的工作环境。
• 操作前请确保计算机断开电源。
• 从抗静电袋取出主板之前，先轻触安全触地器或使用触地手腕带去除静电以确保安
全。
• 避免触摸主板上的零件。手持电路板的边缘，不要折曲或按压电路板。
• 安装之后，确认没有任何小零件置于机箱中，一些小的零件可能引起电流短路并可能
损 坏 设 备。
• 确保计算机远离危险区域，如：高温、潮湿、靠近水源的地方。
• 计算机的工作温度应保持在0-45℃之间
• 为避免受伤，请注意以下幾點：
主板或連接器上尖銳的針腳
机箱上的粗糙边缘和尖角
破损的线缆可能引起短路
1�2 包装清单
• Serial ATA数据线 x2
• ATX机箱后置I/O面板 x1
• 用户手册 x1
• 驱动光盘 x1 (包括安装驱动)
»
此清单可能因销售区域或主板型号不同而异，相关标配详情请咨询当地经销商。
