User’s Manual of SGSD-1022 / SGSD-1022P

SGSW-2840 / SGSW-2840P

223

Figure 4-9-10 IGMP Filter and Throttling Port Configuration page screenshot

The page includes the following fields:

Object Description

• Profile

Selects an existing profile number to assign to an interface.

• Max Multicast Groups

Sets the maximum number of multicast groups an interface can join at the same

time.

Range: 0-255;

Default: 255

• Current Multicast

Groups

Displays the current number of multicast groups the interface has joined.

• Throttling Action Mode

Sets the action to take when the maximum number of multicast groups for the

interface has been exceeded.

(Default: Deny)

-deny - The new multicast group join report is dropped.

-replace - The new multicast group replaces an existing group.

• Throttling Status

Indicates if the throttling action has been implemented on the interface.

Options:

- True

- False

• Trunk

Indicates if a port is a trunk member.
