User’s Manual of SGSD-1022 / SGSD-1022P
SGSW-2840 / SGSW-2840P
255
4.10.3.3 Service Policy
Attaching a Policy Map to Ingress Queues
This function binds a policy map to the ingress queue of a particular interface.
Command Usage
You must first define a class map, then define a policy map, and finally bind the service policy to the required interface.
You can only bind one policy map to an interface.
The current firmware does not allow you to bind a policy map to an egress queue.
1. Click QoS, DiffServ, Service Policy Settings.
2. Check Enabled and choose a Policy Map for a port from the scroll-down box, then click Apply.
Figure 4-10-25 Service Policy Settings page screenshot
The page includes the following fields:
Object Description
Ports
Specifies a port.
Ingress
Applies the rule to ingress traffic.
Enabled
Check this to enable a policy map on the specified port.
Policy Map
Select the appropriate policy map from the scroll-down box.
