User’s Manual of SGSD-1022 / SGSD-1022P

SGSW-2840 / SGSW-2840P

340

4.13 Power Over Ethernet (SGSD-1022P / SGSW-2840P / SGSW-2840P4)

Providing up to 8/24 PoE, in-line power interface, the SGSD-1022P / SGSW-2840P PoE Switch can easily build a power

central-controlled IP phone system, IP Camera system, AP group for the enterprise. For instance, 8 camera / AP can be easily

installed around the corner in the company for surveillance demands or build a wireless roaming environment in the office.

Without the power-socket limitation, the PoE Switch makes the installation of cameras or WLAN AP more easily and efficiently.

4.13.1 Power over Ethernet Powered Device

3~5 watts

Voice over IP phones

Enterprise can install POE VoIP Phone, ATA and other Ethernet/non-Ethernet

end-devices to the central where UPS is installed for un-interrupt power system

and power control system.

6~12 watts

Wireless LAN Access Points

Museum, Sightseeing, Airport, Hotel, Campus, Factory, Warehouse can

install the Access Point any where with no hesitation

10~12 watts

IP Surveillance

Enterprise, Museum, Campus, Hospital, Bank, can install IP Camera without

limits of install location – no need electrician to install AC sockets.

3~12 watts

PoE Splitter

PoE Splitter split the PoE 48V DC over the Ethernet cable into 5/9/12V DC

power output. It frees the device deployment from restrictions due to power

outlet locations, which eliminate the costs for additional AC wiring and reduces

the installation time.
