Motherboard Manual
2
1.3 Motherboard Specifications
Specifications
CPU Support
Socket 1150 for Intel® Core i7 / i5 / i3 / Pentium / Celeron processor
Maximum CPU TDP (Thermal Design Power): 95Watt
* Please refer to
www.biostar.com.tw for CPU support list.
Chipset
INTEL® Z87 (Hi-Fi Z87S2)
INTEL® H87 (Hi-Fi H87S2)
INTEL® B85 (Hi-Fi B85S2)
Memory
Supports Dual Channel DDR3 1066/ 1333/ 1600
Supports Dual Channel DDR3 1800(OC) / 1866(OC) / 2133(OC) / 2200(OC) / 2400(OC) /
2600(OC) for Hi-Fi Z87S2
2 x DDR3 DIMM Memory Slot, Max. Supports up to 16 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 module
* Please refer to
www.biostar.com.tw for Memory support list.
Storage
INTEL® Z87 & H87:
6x SATA 6Gb/s Connector
Supports RAID 0,1,10,5, SRT & AHCI
INTEL® B85:
4x SATA 6Gb/s Connector
2x SATA 3Gb/s Connector
Supports AHCI
LAN
Realtek RTL 8111F
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
Audio Codec
ALC892
7.1 Channels, High Definition Audio, Biostar Hi-Fi
(2-channel output is from front audio header)
USB
4x USB 3.0 port (2 on rear I/Os and 2 via internal headers)
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
Expansion Slots
2x PCI Slot
2x PCIe 2.0 x1 Slot
1x PCIe 2.0 x16 Slot (x4)
1x PCIe 3.0 x16 Slot (x16)
Rear I/Os
1x PS/2 Mouse
1x PS/2 Keyboard
1x HDMI Port
1x VGA Port
1x DVI Port
1x LAN port
2x USB 2.0 Port
2x USB 3.0 Port
3x Audio Jack
