Hi-Fi Z87S2/Hi-Fi H87S2/Hi-Fi B85S2
45
Spezifikationen
Interne I/Os
Hi-Fi Z87S2 & Hi-Fi H87S2
6x SATA 6.0Gb/s-Verbinung
2x USB 2.0-Header
(jeder Header unterstützt 2 USB 2.0-Ports)
1x USB 3.0-Header
(jeder Header unterstützt 2 USB 3.0-Ports)
1x 4-Pin-Stromverbindung
1x 24-Pin-Stromverbindung
1x CPU-Ventilatorverbindung
2x System-Ventilatorverbindung
1x Header für Frontpanel
1x Header für Frontaudio
1x Header für klares CMOS
1x Consumer IR-Header
1x Serieller Port-Header
1x S/PDI-Auswurfsverbindung
1x Header für Druckeranschluss
Hi-Fi B85S2
4x SATA 6.0Gb/s-Verbinung
2x SATA 3.0Gb/s-Verbinung
2x USB 2.0-Header
(jeder Header unterstützt 2 USB 2.0-Ports)
1x USB 3.0-Header
(jeder Header unterstützt 2 USB 3.0-Ports)
1x 4-Pin-Stromverbindung
1x 24-Pin-Stromverbindung
1x CPU-Ventilatorverbindung
2x System-Ventilatorverbindung
1x Header für Frontpanel
1x Header für Frontaudio
1x Header für klares CMOS
1x Consumer IR-Header
1x Serieller Port-Header
1x S/PDI-Auswurfsverbindung
1x Header für Druckeranschluss
Formfaktor ATX Formfaktor, 305 mm x 210 mm
OS-Unterstützung
Windows 7/ 8
Biostar reserves the right to add or remove support for any OS with or without notice.
