Hi-Fi Z87S2/Hi-Fi H87S2/Hi-Fi B85S2
53
Especificações
Conectores na
placa
Hi-Fi Z87S2 & Hi-Fi H87S2
Conector 6x SATA 6.0Gb/s
Dispositivo 2x USB 2.0 (cada Dispositivo
suporta 2 portas USB 2.0)
Dispositivo 1x USB 3.0 (cada Dispositivo
suporta 2 portas USB 3.0)
Conector de 4 pinos x1
Conector de 24 pinos x1
Conector de Ventoinha processador x1
Conector de Ventoinha Sistema x2
Dispositivo Painel Frontal x1
Dispositivo de Audio Frontal x1
Dispositivo CMOS Direct x1
Dispositivo Consumível IR x1
Dispositivo Porta Série x1
Conector Externo S/PDIF x1
Dispositivo Porta Impressora x1
Hi-Fi B85S2
Conector 4x SATA 6.0Gb/s
Conector 2x SATA 3.0Gb/s
Dispositivo 2x USB 2.0 (cada Dispositivo
suporta 2 portas USB 2.0)
Dispositivo 1x USB 3.0 (cada Dispositivo
suporta 2 portas USB 3.0)
Conector de 4 pinos x1
Conector de 24 pinos x1
Conector de Ventoinha processador x1
Conector de Ventoinha Sistema x2
Dispositivo Painel Frontal x1
Dispositivo de Audio Frontal x1
Dispositivo CMOS Direct x1
Dispositivo Consumível IR x1
Dispositivo Porta Série x1
Conector Externo S/PDIF x1
Dispositivo Porta Impressora x1
Fator de Fôrma Fator de Fôrma ATX, 305 mm x 210 mm
Suporte OS
Windows 7/ 8
Biostar reserva seu direito de adicionar ou retirar o suporte para qualquer OS com ou sem
notificação.
