Motherboard Manual
48
Japanese
仕様
CPU サポート
Intel® Core i7 / i5 / i3 / Pentium / Celeron プロセッサの Socket 1150
最大 CPU TDP （Thermal Design Power 最大放熱量）:95 W
*CPU サポート リストについては、
www.biostar.com.twを参照してください。
チップセット
INTEL® Z87 (Hi-Fi Z87S2)
INTEL® H87 (Hi-Fi H87S2)
INTEL® B85 (Hi-Fi B85S2)
メモリ
デュアルチャンネル1066/ 1333/ 1600 をサポート
デュアルチャンネル1800(OC) / 1866(OC) / 2133(OC) / 2200(OC) / 2400(OC) / 2600(OC)
をサポート (Hi-Fi Z87S2)
2 x DDR3 DIMM メモリ スロット、 最大 16 GB メモリまでサポート
各 DIMM は、非-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 モジュールをサポートしています
*サポートされているメモリのリストについては、
www.biostar.com.twを参照してくだ
さい。
保存スペース
INTEL® Z87 & H87:
6x SATA 6Gb/s コネクタ
RAID 0,1,10,5, SRT & AHCI のサポート
INTEL® B85:
4x SATA 6Gb/s コネクタ
2x SATA 3Gb/s コネクタ
AHCI のサポート
LAN
Realtek RTL 8111F
10/ 100/ 1000 Mb/s オートネゴーシエーション、半/全 二重通信
オーディオ コーデ
ック
ALC892
7.1 チャンネル, ハイ デフィニション オーディオ, Biostar Hi-Fi
USB
4x USB 3.0 ポート (後部 I/O に2つ 及び 内蔵 ヘッダー経由に2つ)
6x USB 2.0 ポート (後部 I/O に2つ 及び 内蔵ヘッダー経由に4つ)
拡張スロット
2x PCI スロット
2x PCIe 2.0 x1 スロット
1x PCIe 2.0 x16 スロット(x4)
1x PCIe 3.0 x16 スロット(x16)
後部 I/O
1x PS/2 マウス
1x PS/2 キーボード
1x HDMI ポート
1x VGA ポート
1x DVI ポート
1x LAN ポート
2x USB 2.0 ポート
2x USB 3.0 ポート
3x オーディオ ジャック
