Hi-Fi Z87S2/Hi-Fi H87S2/Hi-Fi B85S2
49
仕様
内蔵 I/O
Hi-Fi Z87S2 & Hi-Fi H87S2
6x SATA 6.0Gb/s コネクタ
2x USB 2.0 ヘッダー
(各ヘッダーは、2つの USB 2.0 ポートを
サポートしています)
1x USB 3.0 ヘッダー
(各ヘッダーは、2つの USB 3.0 ポートを
サポートしています)
1x 4-Pin パワー コネクタ
1x 24-Pin パワー コネクタ
1x CPU ファン コネクタ
2x システム ファン コネクタ
1x フロント パネル ヘッダー
1x フロント オーディオ ヘッダー
1x クリア CMOS ヘッダー
1x コンシューマー IR ヘッダー
1x シリアル ポート ヘッダー
1x S/PDIF アウト コネクタ
1x プリンター ポート ヘッダー
Hi-Fi B85S2
4x SATA 6.0Gb/s コネクタ
2x SATA 3.0Gb/s コネクタ
2x USB 2.0 ヘッダー
(各ヘッダーは、2つの USB 2.0 ポートをサポ
ートしています)
1x USB 3.0 ヘッダー
(各ヘッダーは、2つの USB 3.0 ポートをサポ
ートしています)
1x 4-Pin パワー コネクタ
1x 24-Pin パワー コネクタ
1x CPU ファン コネクタ
2x システム ファン コネクタ
1x フロント パネル ヘッダー
1x フロント オーディオ ヘッダー
1x クリア CMOS ヘッダー
1x コンシューマー IR ヘッダー
1x シリアル ポート ヘッダー
1x S/PDIF アウト コネクタ
1x プリンター ポート ヘッダー
フォーム ファクタ ATX フォーム ファクタ、305 mm x 210 mm
サポート OS
Windows 7/ 8
Biostar には、通知なしでサポート OS を変更する権限があります。
