Hi-Fi Z87S2/Hi-Fi H87S2/Hi-Fi B85S2
3
Specifications
Internal I/Os
Hi-Fi Z87S2 & Hi-Fi H87S2
6x SATA 6.0Gb/s Connector
2x USB 2.0 Header
(each header supports 2 USB 2.0 ports)
1x USB 3.0 Header
(each header supports 2 USB 3.0 ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
2x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x Consumer IR Header
1x Serial Port Header
1x S/PDIF out Connector
1x Printer Port Header
Hi-Fi B85S2
4x SATA 6.0Gb/s Connector
2x SATA 3.0Gb/s Connector
2x USB 2.0 Header
(each header supports 2 USB 2.0 ports)
1x USB 3.0 Header
(each header supports 2 USB 3.0 ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
2x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x Consumer IR Header
1x Serial Port Header
1x S/PDIF out Connector
1x Printer Port Header
Form Factor ATX Form Factor, 305 mm x 210 mm
OS Support
Windows 7/ 8
Biostar reserves the right to add or remove support for any OS with or without notice.
