• Item
Description
• VLAN Type -
There’re two VLAN mode support – 802.1Q VLAN and Port-Bas VLAN
• 802.1Q – Packets income will be tagged with VID as the PVID setting. All ports
on the switch belong to default VLAN (VID 1).
• Port-Base - Packets can only be broadcast among other members of the
same VLAN group. Note all unselected ports are treated as belonging to the
default system VLAN.
If port-based VLAN are enabled, then VLAN-tagging feature is ignored.
• Port -
Select the physical interface for which you want to display or configure data.
• Link Type -
Allow 802.1Q Untagged or Tagged VLAN for selected port.
When adding a VLAN to selected port, it tells the switch whether to keep or
remove the tag from a frame on egress.
• Untag: outgoing frames without VLAN-Tagged.
• Tagged: outgoing frames with VLAN-Tagged.
• Ingress Filtering
Enable-
Enabled - the frame is discarded if this port is not a member of the VLAN with
which this frame is associated. In a tagged frame, the VLAN is identified by the
VLAN ID in the tag. In an untagged frame, the VLAN is the Port VLAN ID specified
for the port that received this frame.
Disabled - all frames are forwarded in accordance with the 802.1Q VLAN bridge
specification. The factory default is disabled.
• Acceptable Frame
Types -
Specifies the types of frames that may be received on this port. The options are
'All' and 'Tagged only'.
• All- untagged frames or priority tagged frames received on this port are
accepted and assigned the value of the Port VLAN ID for this port.
• Tagged only - untagged frames or priority tagged frames received on this port
are discarded.
With either option, VLAN tagged frames are forwarded in accordance to the
802.1Q VLAN specification.
• PVID -
Allow assign PVID for selected port. The range for the PVID is 1-4094
The PVID will be inserted into all untagged frames entering the ingress port. The
PVID must as same as the VLAN ID that the port belong to VLAN group, or the
untagged traffic will be dropped.
Table 4-7 Description of the VLAN Per Port Configuration
-24-
