4.14.7 Web Smart Function
This function could provide you to define device indicate connect to each port on Web Smart Switch, the screen in Figure
4-62 appears.
Figure 4-62 Web Smart Function Web Page screen
The available options are shown as below: Table 4-32 Description of the Web smart function.
• Item
Description
• PC
• PC+Voip
• Switch
• Router
• AP
• Server
• Printer
• Guest
