User’s Manual of GSD-800S / GSD-802S / GSD-802PS
Product Features
Physical Port
GSD-800S
z 8-Port 10/100/1000Base-T RJ-45 Copper ports.
GSD-802S
z 8-Port 10/100/1000Base-T RJ-45 Copper with 2 Shared SFP / mini-GBIC slots
GSD-802PS
z 8-Port 10/100/1000Base-T RJ-45 Copper with 2 Shared SFP / mini-GBIC slots
Generic Features
z Comply with IEEE 802.3, 10Base-T, IEEE 802.3u, 100Base-TX, IEEE 802.3ab,1000Base-T, IEEE
802.3z,1000Base-SX/LX, Ethernet standard
z Auto-MDI/MDI-X detection on each RJ-45 port
z Prevents packet loss with back pressure (half-duplex) and 802.3x PAUSE frame flow control (Full-duplex)
z 8K MAC address table, automatic source address learning and ageing
z 16Gbps switch fabric, non-blocking switch architecture
z 9K Jumbo Frame support at all speed (10/100/1000 Mbps)
Layer-2 Switching
z Support port-based and 802.1q VLAN function, up to 64 VLAN groups
z 802.1w Rapid-Spanning Tree protocol support
z Link Aggregation support static mode and LACP (802.3ad) - up to 4 Trunk groups, each trunk for up to
maximum 8 ports
z IGMP Snooping – multicast filtering
Quality of Service
z 4 QoS classes per port
z Traffic class assignment based on 802.1p tag, or DSCP field
z Multicast and Broadcast Storm Control as well as Flooding Control
Security
z Port Mirroring support for dedicated port monitoring
z 802.1X Port-Base access control, RADIUS ServerAuthentication
z Static MAC Address assign destination MAC address at specifies port
Power over Ethernet (GSD-802PS)
z Per Port PoE Full power support
z Powered Device Auto detection
z Power Interface Protection
z LED easy PoE status Monitoring
