2. INSTALLATION

This section describes the functionalities of the Gigabit Ethernet

Switch’s components and guides how to install it on the desktop.

Basic knowledge of networking is assumed. Please read this

chapter completely before continuing.

In the following section, the term “Gigabit Ethernet Switch”

means the GSD-805.

2.1 Product Description

The PLANET GSD-805 is 8-Port 10/100/1000Mbps Gigabit

Ethernet Switch with non-blocking wire-speed performance and

new metal shape for easily desktop deployment in compact

housing or SOHO application.

With a 16Gbps internal switching fabric, the Gigabit Ethernet

Switch can handle extremely large amounts of data in a secure

topology linking to a backbone or high capacity servers.

The Gigabit Ethernet Switch has 4K MAC Address table and

offers wire-speed packets transfer performance without risk of

packet loss. The Gigabit ports with 9K jumbo packet support

can handle large amounts of data transmission in a secure

topology linking to a backbone or high-power servers. The

high data throughput of the device makes it ideal for most

Gigabit environments, especially network upgrades to a Gigabit

environment.

All RJ-45 copper interfaces support 10/100/1000Mbps Auto-

Negotiation for optimal speed detection through RJ-45 Category

6, 5 or 5e cables. Support standard for Auto-MDI/MDI-X that

can detect the type of connection to any Ethernet device without

requiring special straight or crossover cables.

The Flow Control function allows Gigabit Ethernet Switch
