1.3 Product Features
● Comply with IEEE 802.3, 10Base-T, IEEE 802.3u 100Base-TX,
IEEE 802.3ab 1000Base-T Ethernet standard
● 8-Port 10/100/1000Mbps Gigabit Ethernet ports
● Features Store-and-Forward mode with wire-speed ltering
and forwarding rates
● Hardware based 10/100Mbps, half / full duplex and 1000Mbps
full duplex mode, ow control and auto-negotiation
● IEEE 802.3x ow control for full duplex operation and Back
pressure for half duplex operation
● Integrated address look-up engine, support 4K absolute MAC
addresses
● 1Mbit on-chip frame buffer
● 9K Jumbo packet support
● Automatic address learning and address aging
● Supports Auto MDI/MDI-X function
● Support CSMA/CD protocol
● Internal power adapter 100-240V AC, 50/60Hz, 0.2A
● FCC, CE class A compliant
