8
1.4 Product Specications
Product GSD-805
Hardware Specication
10/100/1000Base-T
Ports
8
Dimensions
(W x D x H)
191 mm x 85 mm x 26 mm
Weight 390g
Power Requirement
Internal power 100-240V AC, 50/60Hz,
0.2A
Power Consumption
/ Dissipation
9.6 watts / 32 BTU
Switch Specication
Switch Processing
Scheme
Store-and-Forward
Address Table 4K entries
Share data Buffer 1Mbit on-chip frame buffer
Flow Control
Back pressure for half duplex, IEEE
802.3x Pause Frame for full duplex
Switch fabric 16Gbps
Throughput
(packet per second)
11.9Mpps
Network cables
10/100/1000Base-T:
Cat. 3, 4, 5, 5e, 6 UTP cable
(100meters, max.)
EIA/TIA-568 100-ohm STP
(100meters, max.)
