User’s Manual of GSD-800S / GSD-802S / GSD-802PS

• Pair

The twist pair of the UTP cable. The pair groups as follow:

A (Pin 1,2)

B (Pin 3,6)

C (Pin 4,5)

D (Pin 7,8)

• Length[m]

When properly terminated, Cable Diagnostics reports the approximate cable

length in meters of each of the four cable pair A, B, C, and D.

• Status

The cable test results. Possible values are:

• Proper - The cable passed the test.

• Open - The cable is connected on only one side or there is no cable connected

to the port

• Short - A short has occurred in the cable. With 10/100BASE link, the status of

Pair C and Pair D will be “Short”.

• Abnormal termination – An improper termination be detected. Proper

termination of Cat5 cable requires a 100

Ω differential impedance between

the positive and negative cable terminals. IEEE Std 802.3 allows for a

termination of as large as 115Ω or as small as 85Ω. If the termination

falls out of this range, it is reported as falls an anomalous termination.

#Notice:

Be sure to running the Cable diagnostics with standard Cat 5e or Cat 6 UTP cable. With some of the

UTP cables that not match the standard of Cat 5e, it might cause the 10/100Base link down after the

cable diagnostics.
