Motherboard Manual
30
SPANISH
Especificación
CPU
Socket 1155
Proces ador Intel Cor e i7 / i5 / i3 / Pent iu m /
Celeron
Admite Bit de deshabilitación de ejecución / Intel
SpeedStep® Mejorado / Int el Architecture-64 /
Tecno log ía Extended Memory 64 / Tecno logía de
virtualización / Hyper Threading
Conjunto de
chips
Intel H61
Súper E/S
IT8772E
Le ofrece las funcionalidades heredadas de
uso más común Súper E /S.
Interfaz de cuenta Low Pin
In ic iat ivas de control d e entorno,
Monitor hardware
Controlador/monitor de velocidad de ventilador
Función "Guardia inteligente" de ITE
Memoria
principal
Ranuras DIMM DDR3 x 2
Capacidad máxima de memoria de 16GB
Cada DIMM admite DDR de
512MB/1GB/2GB/4GB/8GB
Módulo de memoria DDR3 de canal Doble
Admite DDR3 de 1066 / 1333 / 1600
No admite DIMM registrados o DIMM compatibles
con ECC
SATA 2
Controlador ATA Serie Integrado
Tasas de transferencia de hasta 3.0 Gb/s.
Compat ib le con la versión SATA 2.0
Red Local
RTL8111F (H61MHV & H61MGV)
RTL8105E (H61MLC2)
Negociación de 10 / 100 / 1000 Mb/s
Negociación de 10 / 100 Mb/s
Soporte de
sonido HD
ALC662
Soporte de sonido de Alta Definición
Salida de sonido de 5.1 canales
Ranuras
Ranura PCI-E Gen3 x16 X1 (dependiendo de la CPU)
Ranura PCI-E Gen2 x 1 X1
Conectores
en placa
Conector SATA2 X4 Cada conector soporta 1 dispositivos SATA2
Conector de panel frontal X1 Soporta instalaciones en el panel frontal
Conector de sonido frontal X1 Soporta funciones de sonido en el panel frontal
Cabecera de ventilador de CPU X1 Fuente de alimentación de ventilador de CPU (con
función Smart Fan)
Cabecera de ventilador de sistema X1 Fuente de alimentación de ventilador de sistema
