Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket 1155
Inte l Core i7 / i5 / i3 / Pent ium / C eleron
processor
Supports Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization Technology
/
Hyper Threading
Chipset
Intel H61
Super I/O
IT8772E
Provides the most commonly used leg acy
Super I/O functionality
Low Pin Count Interface
Environment Control in it iatives
Hardware Monitor Controller
Fan Sp eed Contro ller
ITE's "S mart Guardian " funct ion
Main
Memory
DDR3 DIMM Slots x 2
Max Memory Capacity 16GB
Each DIMM supports 512MB/
1GB/2GB/4GB/8GB DDR3
Dual Channel Mode DDR3 memory modu le
Supports DDR3 1066 / 1333
Supports DDR3 1600 (depending on CPU)
Registered DIMM and ECC DIMM is not supported
SATA 2
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s
SATA Vers ion 2.0 specif icat ion co mp liant
LAN
RTL8111F (H61MHV & H61MGV)
RTL8105E (H61MLC2)
10 / 100 / 1000Mb/s auto negotiation
10 / 100 Mb/s auto negotiation
Sound
Codec
ALC662
5.1 channels audio out
High Definition Audio
Slots
PCI-E Gen3x16 slot x1
(depend ing on CPU)
Supports PCI-E Gen2/3 x16 expansion card
PCI-E Gen2 x1 slot x1 Supports PCI-E Gen2 x1 expansion card
On Board
Connectors
SATA2 Connector x4 Each connector supports 1 SATA2 device
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
CPU Fan Header x1 CPU Fan power supply (with Smart Fan function)
System Fan Header x1 System Fan Power supply
Clear C MOS Header x1 Restore CMOS dat a to factory default
