Motherboard Manual
40
JAPANESE
仕様
CPU
Socket 1155
Intel Core i7 / i5 / i3 / Pent iu m / C eleron プロ
セッサ
Execute Disable Bit / Enhanced Intel SpeedStep® /
Intel Architecture-64 / Extended Memory 64
Technology / Virtualization Technology / Hyper
Threadingをサポートします
チップセット
Intel H61
メインメモリ
DDR3 DIMMスロット x 2
最大メモリ容量16GB
各DIMMは 512MB/1GB/2GB/4GB/8GB DDR3
をサポート
デュアル チャンネルモードDDR3メモリモジュール
DDR3 1066 / 1333 / 1600をサポート
登録済みDIMMとECC DIMMはサポートされません
Super I/O
IT8772E
もっとも一般に使用されるレガシーSuper I/O機
能を採用しています。
低ピンカウントインターフェイス
環境コントロールイニシアチブ、
H/Wモニター
ファン速度コントローラ/ モニター
ITEの「スマートガーディアン」機能
SATA 2
統合シリアルATA コントローラ
最高3.0 Gb/秒のデータ転送速度
SATAバージョン2.0仕様に準拠
LAN
RTL8111F (H61MHV & H61MGV)
RTL8105E (H61MLC2)
10 / 100 / 1000 Mb/秒のオートネゴシエーション
10 / 100 Mb/秒のオートネゴシエーション
HDオーディ
オのサポート
ALC662
ハイデフィニションオーディオのサポート
5.1 チャンネルオーディオアウト
スロット
PCI-E Gen3 x16スロット x1 (CPUに依存）
PCI Express Gen2 x 1スロット x1
オンボードコ
ネクタ
SATA2コネクタ x4 各コネクタは1つのSATA2デバイスをサポートします
フロントパネルコネクタ x1 フロントパネル機能をサポートします
フロントオーディオコネクタ x1 フロントパネルオーディオ機能をサポートします
CPUファンヘッダ x1 CPUファン電源装置(スマートファン機能を搭載)
システムファンヘッダ x1 システムファン電源装置
CMOSクリアヘッダ x1
