Motherboard Manual
36
RUSSIAN
СПЕЦ
CPU
(центральн
ый
процессор)
Socket 1155
Процессор Inte l Core i7 / i5 / i3 / Pent iu m /
Celeron
Поддержка технологий Execute Disable Bit /
Enhanced Intel SpeedStep® / Intel Architecture-64
/ Extended Memory 64 Technology / технологии
виртуализация / Hyper Threading
Набор
микросхем
Intel H61
Основная
память
Слоты DDR3 DIMM x 2
Максимальная ёмкость памяти 16 ГБ
Каждый модуль DIMM поддерживает
512МБ /1ГБ/2ГБ/4ГБ/8ГБ DDR3
Модуль памяти с двухканальным режимом DDR3
Поддержка DDR3 1066 / 1333 / 1600
Не поддерживает зарегистрированные модули
DIMM and ECC DIMM
Super I/O
IT8772E
Обеспечивает наиболее используемые
действующие функциональные
возможности Super I/O.
Интерфейс с низким количеством выводов
Инициативы по охране окружающей среды,
Аппаратный монитор
Регул ятор скорости вентилятора/ монитор
Функц ия ITE "Smart Guardian"
(Интеллектуальная защита)
SATA 2
Встроенное последовательное устройство
управления ATA
скорость передачи данных до 3.0 гигабит/с.
Соответствие спецификации SATA версия 2.0
Локальная
сеть
RTL8111F (H61MHV & H61MGV)
RTL8105E (H61MLC2)
Автоматическое согласование 10/ 100 /1000 Мб /с
Автоматическое согласование 10/ 100 Мб /с
Звуковая
поддержка
жесткого
диска
ALC662
Звуковая поддержка High-Defin ition
5.1канальный звуковой выход
Слоты
Слот PCI-E Gen3 x16 @ x16 x1 (в зависимости от процессора)
Слот PCI-E Gen2 x 1 x1
Встроенны
й разъём
Разъём SATA2 x4 Каждый разъём поддерживает 1 устройство SATA2
Разъём на лицевой панели x1 Поддержка устройств на лицевой панели
Входной звуковой разъём x1
Поддержка звуко вых функций на лицевой
панели
Контактирующее приспособление
вентил ятора центрального процессора x1
Источник питания для вентилятора центрального
процессора (с фун кц ией интеллектуального
вентил ятора)
