A.3 Cable Connection Parameter

The limitations are shown as below;

Standard Fiber Type Cable Specification

1000Base-SX

(850nm)

Multi-mode 50/125μm or 62.5/125μm

Multi-mode 50/125μm or 62.5/125μm 1000Base-LX

(1300nm)

Single-mode 9/125μm

Wiring Distances:

Standard Fiber Diameter

(micron)

Modal Bandwidth

(MHz * km)

Max. Distance

(meters)

1000Base-SX MM 62.5

62.5

100

200

400

220

275

500

550 500

MM 62.5

550

1000Base-LX

SM 9 N/A 5000*

#Notice:

1: Consult your local dealer for more about PLANET single mode fiber connectivity.

2. The Single-mode port (1000Base-LX port) of GST-702S, GST-705A, GST-706A15/B15 and GST-706A60/B60 is

complied with LX 5 kilometers and provides additional margin allowing for a

10/15/60 kilometers Gigabit Ethernet link on

single mode fiber.

3. A model (TX: 1310nm; RX: 1550nm) and B model (TX: 1550nm; RX: 1310nm) should runs in pair.
