Planet GST-705A [5/17] Specification

- 5 -

1.4 Specification

Model GST-702 GST-702S GST-705 GST-705A GST-

706A15

GST-

706B15

GST-

706A60

GST-

706B60

Hardware Specification

Standards IEEE 802.3ab 1000Base-T, IEEE 802.3z 1000Base-LX/SX

Ports 1 1000Base-T port , 1 1000Base-LX/SX port

Fiber connector SC SC LC SFP, LC WDM WDM WDM WDM

Cable 1000Base-T: 2-pair Cat. 5,5e,6 UTP cable, up to 100 meters

1000Base-SX: 50/125μm or 62.5/125μm multi-mode fiber cable, up to 220/550m.

1000Base-LX: 9/125μm single-mode cable, provide long distance for 10/20/40/50/70/120km

LED indicator System: PWR

TP: LNK,ACT

LX / SX: LNK, ACT, FDX

DIP switch Fiber ( Auto-negotiation / Manual), LLR( Disable / Enable)

Speed Gigabit Ethernet: 1000/2000Mbps for half / full-duplex

Power input DC 5V 2A

Power consumption 6.2 Watts / 21 BTU( maximum)

Operate environment 0~50 Degree C, 5%~90%RH

Storage environment -20~70 Degree C, 5%~90%RH

Dimension (W x D xH) 81 x 94 x 26mm

Weight 0.22kg

Emission FCC Class B, CE mark
