TA785G3 HD/ TA880G+ BIOS Manual
17
785G HD Audio
This item allows you to control 785G HD audio function.
Options: Enabled (Default) / Disabled
HD Audio Azalia Device
This item allows you to control the HD audio device.
Options: Enabled (Default) / Auto / Disabled
Onboard LAN Configuration
BIOS SETUP UTILITY
Advanced
vxx.xx (C)Copyright 198 5-200x, American Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Enable/Disable
Onboard Realtek
PCIE Network
Controller
Onboard LAN Config uration
MAC ID Information :
Realtek PCIE NIC [Enabled]
Realtek Option RO M [Disabled]
MAC ID Information
This area shows the MAC ID.
Realtek PCIE NIC
This option allows you to control the onboard LAN controller.
Options: Enable (Default) / Disable
Realtek Option ROM
This item allows you to enable or disable the Onboard LAN Boot ROM.
Options: Disabled (Default) / Enabled
