TA785G3 HD/ TA880G+ BIOS Manual
39
BIOSTAR Memory Insight
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
BIOSTAR Memory Insight
DDR3-A1 SPD Informations
DDR3-B1 SPD Informations
DDR3-A2 SPD Informations
DDR3-B2 SPD Informations
DDR3-A1 SPD Informatio
T-Series
DDR3-A1/B1/A2/B2 SPD Informations
These items display SPD information of DDR3 memory.
Memory Clock Mode
This item allows you to control the Memory Clock.
Options: Auto (Default) / Limit / Manual
Memclock Value
This item allows you to set the Memory Clock.
Options: DDR3-800 (Default) / DDR3-1066 / DDR3-1333 / DDR3-1600 / Auto
DRAM Timing M ode
This item allows you to choose to manually or automatically regulate the DRAM
Timing.
Options: Auto (Default) / DCT0 / DCT1 / Both
CAS Latency (CL)
Options: Auto (Default) / 4~12 CLK
2T Command
Options: Auto (Default) / 1T / 2T
