TA785G3 HD/ TA880G+ BIOS Manual
28
South Bridge Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, Amer ican Megatre nds, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
OHCI HC(Bus 0 Dev 18 Fn o) [ Enabled]
SouthBridge Chipset Configurat ion
SB710 CIMx Verison: 4.7.0
OHCI HC(Bus 0 Dev 18 Fn 1) [ Enabled]
EHCI HC(Bus 0 Dev 18 Fn 2) [ Enabled]
OHCI HC(Bus 0 Dev 19 Fn 0) [ Enabled]
OHCI HC(Bus 0 Dev 19 Fn 1) [ Enabled]
EHCI HC(Bus 0 Dev 19 Fn 2) [ Enabled]
OHCI HC(Bus 0 Dev 20 Fn 5) [ Enabled]
OnChip SATA Channel [ Enabled]
OnChip SATA Type [ Native IDE]
Option ROM POST Delay [ Disabled]
SATA IDE Combined Mode [ Enabled]
Power Saving Features [ Disabled]
Options
Disabled
Enabled
OHCI HC(Bus 0 Dev 18/19/20 Fn 0/1/5)
This item allows you to control OHCI host controller. (USB 1.1 Device)
Options: Enabled (Default) / Disabled
EHCI HC(Bus 0 Dev 18/19 Fn 2)
This item allows you to control EHCI host controller. (USB 2.0 Device)
Options: Enabled (Default) / Disabled
OnChip SATA Channel
This option allows you to enable the on-chip Serial ATA.
Options: Enabled (Default) / Disabled
OnChip SATA Type
This option allows you to select the on-chip Serial ATA operation mode.
Options: Native IDE (Default) / RAID / AHCI / Legacy IDE / IDEÆAHCI
Option ROM POST Delay
Options: Disabled (Default) / 1 Second / 2 ~ 7 Seconds
