TA785G3 HD/ TA880G+ BIOS Manual
33
Over-Voltage Configuration
BIOS SETUP UTILITY
vxx.xx (C)Copyright 198 5-200x, American Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Over-Voltage Confi guration
CPU Vcore [Auto]
[Auto]CPU NB Over Voltag e
Chipset Over-Volta ge [1.25V]
HT Over-Voltage [1.22V]
Side Port Over-Vol tage [1.54V]
Memory Over-Voltag e [1.61V]
Performance
CPU Vcore Contro l
CPU Vcore
This item allows you to select CPU Voltage Control.
Options: Auto (Default) / +0.050V ~ +1.450V (Interval: 0.050V)
CPU NB Over Voltage
This item allows you to select CPU NB Voltage Control.
Options: Auto (Default) / +0.050V ~ +1.450V (Interval: 0.050V)
Memory Over-Voltage
This item allows you to select Memory Voltage Control.
Options: 1.61V (Default) / 1.51V / 1.55V / 1.64V /1.70V / 1.74V / 1.80V / 1.84V
Chipset Over-Voltage
This item allows you to select Chipset Voltage Control.
Options: 1.25V (Default) / 1.36V / 1.46V / 1.55V
HT Over-Voltage
This item allows you to select HT Voltage Control.
Options: 1.22V (Default) / 1.32V / 1.42V / 1.52V
