TA785G3 HD/ TA880G+ BIOS Manual
24
Internal Graphics Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Internal Graphics Configuration
UMA Frame Buffer Size [Auto]
SIDEPORT Clock Speed
GFX Engine clock Override [Disable]
UMA-SP Interleave Mode [Auto]
SP Power Managment [Auto]
SP NB Termination [Auto]
SP Memory Termination [Auto]
SP CMD Hold [Auto]
SP DATA Hold [Auto]
FB Location [Above 4G]
Internal Graphics Mode [UMA+SIDEPORT]
[533MHz]
Surround View [Auto]
Options
Disable
UMA
UMA+SIDEPORT
Internal Graphics Mode
This item allows you to select the memory mode used for internal graphics device.
Options: UMA+SIDEPORT (Default) / UMA / Disable
UMA Frame Buffer Size
This item allows you to choose the UMA frame buffer size for internal graphics.
Options: Auto (Default) / 32MB / 64MB / 128MB / 256MB / 512MB
SIDEPORT Clock Speed
This item allows you to choose the SIDEPORT Clock Speed for internal graphics.
Options: 533MHz (Default) / 333MHz+ / 350MHz / 366MHz / 400MHz / 425MHz
/ 466MHz / 667MHz
GFX Engine Clock Override
This item allows you to control the internal GFX engine clock override function.
Options: Disabled (Default) / Enabled
GFX Engine Clock
This item allows you to set the internal GFX engine clock.
Options: 500 (Default) / Min: 150, Max: 1200
UMA-SP Interleave Mode
Auto—Fine interleave Ratio/Size selected based on system configuration (HT
Frequency, number of memory channel).
Options: Auto (Default) / Coarse / Fine
