TA785G3/TA780G3/TA760G3 BIOS Manual
11
Control Mode
This item provides several operation modes of the fan.
Options: Quiet / Performance / Manual
Fan Ctrl OFF(℃ )
If the CPU/System Temperature is lower than the set value, FAN will turn off.
Options: 0~127 (℃) (With the interval of 1℃)
Fan Ctrl On(℃ )
CPU/System fan starts to work under smart fan function when arrive this set value.
Options: 0~127 (℃) (With the interval of 1℃)
Fan Ctrl Start Value
When CPU/System temperature arrives to the set value, the CPU/System fan will
work under Smart Fan Function mode.
Options: 0~127 (With the interval of 1)
Fan Ctrl Sensitive
Increasing the value will raise the speed of CPU/System fan.
Options: 1~127 (With the interval of 1)
Hardware Health Configuration
This item shows the system temperature, fan speed, and voltage information.
Advanced
Hardware Health Configuration
H/W Health Function [Enabled]
Shutdown Temperature [Disabled]
CPU
SYS Temperature
CPU Fan
System1 Fan
CPU Voltage
Chip Voltage
+3.30V
+5.00V
+12.0V
DDR Voltage
HT Voltage
Temperature
System2 Fan
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Enables Hardware
Health Monitoring
Device.
Содержание
- Ta785g3 ta780g3 ta760g3 bios manual 1
- Acpi support 2
- Apm support 2
- Bios setup 2
- Epa green pc support 2
- Introduction 2
- Plug and play support 2
- Ta785g3 ta780g3 ta760g3 bios manual 2
- Dram support 3
- Notice 3
- Pci bus support 3
- Supported cpus 3
- Ta785g3 ta780g3 ta760g3 bios manual 3
- Using setup 3
- Ami bios 4
- Main menu 4
- Once you enter ami bios setup utility the main menu will appear on the screen providing an overview of the basic system information 4
- Set the system date note that the day automatically changes when you set the date 4
- Set the system internal clock 4
- Shows system information including bios version and built date 4
- Shows system memory size 4
- System date 4
- System memory 4
- System time 4
- Ta785g3 ta780g3 ta760g3 bios manual 4
- Floppy a 5
- Ide configuration 5
- Select the type of floppy disk drive installed in your system options 360k 5 5 in 1 m 5 5 in 720k 3 in 1 4m 3 in 2 8m 3 in none 5
- Ta785g3 ta780g3 ta760g3 bios manual 5
- To enter the sub menu of detailed options 5
- Ta785g3 ta780g3 ta760g3 bios manual 6
- Ta785g3 ta780g3 ta760g3 bios manual 7
- Advanced menu 8
- Beware of that setting inappropriate values in items of this menu may cause system to malfunction 8
- Cpu configuration 8
- Notice 8
- Ta785g3 ta780g3 ta760g3 bios manual 8
- The advanced menu allows you to configure the settings of cpu super i o power management and other system devices 8
- This item shows the cpu information that the bios automatically detects 8
- Ta785g3 ta780g3 ta760g3 bios manual 9
- Superio configuration 10
- Ta785g3 ta780g3 ta760g3 bios manual 10
- Choose this item and then the bios will auto test and detect the cpu system fan functions and show cpu system fan speed 11
- Cpu smart fan 11
- Mouse poweron 11
- Restore on ac power loss 11
- Smart fan calibration 11
- Smart fan configuration 11
- Ta785g3 ta780g3 ta760g3 bios manual 11
- This item allows you to control the cpu smart fan function options disabled default auto 4pin 3pin 11
- This item allows you to control the mouse power on function options disabled default enabled 11
- This setting specifies how your system should behave after a power fail or interrupts occurs by choosing disabled will leave the computer in the power off state choosing enabled will restore the system to the status before power failure or interrupt occurs options power off default power on last state 11
- Hardware health configuration 12
- Ta785g3 ta780g3 ta760g3 bios manual 12
- Power configuration 13
- Ta785g3 ta780g3 ta760g3 bios manual 13
- Ta785g3 ta780g3 ta760g3 bios manual 14
- Ta785g3 ta780g3 ta760g3 bios manual 15
- Usb configuration 15
- Bios ehci hand off 16
- Ta785g3 ta780g3 ta760g3 bios manual 16
- This item allows you to enable support for operating systems without an ehci hand off feature options enabled default disabled 16
- Usb mass storage dev ice configuration 16
- Usb mass storage reset delay this item allows you to set the reset delay for usb mass storage device options 20 sec default 10 sec 30 sec 40 sec emulation type this item allows you to select the emulation type of the usb mass storage device options auto default floppy forced fdd hard disk cdrom 16
- Beware of that setting inappropriate values in items of this menu may cause system to malfunction 17
- Clear nvram 17
- Notice 17
- Pcipnp menu 17
- Plug play os 17
- Ta785g3 ta780g3 ta760g3 bios manual 17
- This item allows you to clear the data in the nvram cmos by selecting yes options no default yes 17
- This section describes configuring the pci bus system pci or personal computer interconnect is a system which allows i o devices to operate at speeds nearing the speed of the cpu itself uses when communicating with its own special components 17
- When set to yes bios will only initialize the pnp cards used for the boot sequence vga ide scsi the rest of the cards will be initialized by the pnp operating system like window 95 when set to no bios will initialize all the pnp cards for non pnp operating systems dos netware this option must set to no options no default yes 17
- Allocate irq to pci vga 18
- Palette snooping 18
- Pci ide busmaster 18
- Pci latency timer 18
- Pci resource 18
- Some old graphic controllers need to snoop on the vga palette and then map it to their display as a way to provide boot information and vga compatibility this item allows such snooping to take place options disabled default enabled 18
- Ta785g3 ta780g3 ta760g3 bios manual 18
- This item allows bios to choose a irq to assign for the pci vga card options yes default no 18
- This item controls how long a pci device can hold the pci bus before another takes over the longer the latency the longer the pci device can retain control of the bus before handing it over to another pci device options 64 default 0 255 18
- This item is a toggle for the built in driver that allows the onboard ide controller to perform dma direct memory access transfers options enabled default disabled 18
- Pci express configuration 19
- Ta785g3 ta780g3 ta760g3 bios manual 19
- Boot device priority 20
- Boot menu 20
- Hard disk drives 20
- Items in this sub menu specify the boot device priority sequence from the available devices the number of device items that appears on the screen depends on the number of devices installed in the system options removable hard disk cdrom legacy lan disabled 20
- Removable drives 20
- Ta785g3 ta780g3 ta760g3 bios manual 20
- The bios will attempt to arrange the hard disk boot sequence automatically you can also change the booting sequence the number of device items that appears on the screen depends on the number of devices installed in the system options pri master pri slave sec master sec slave usb hdd0 usb hdd1 usb hdd2 bootable add in cards 20
- The bios will attempt to arrange the removable drive boot sequence automatically you can also change the booting sequence the number of device items that appears on the screen depends on the number of devices installed in the system options floppy disks zip100 usb fdd0 usb fdd1 usb zip0 usb zip1 ls120 20
- This menu allows you to setup the system boot options 20
- Addon rom display mode 21
- Boot success beep 21
- Bootup num lock 21
- Cd dvd drives 21
- Full screen logo show 21
- Ignore memory error messages 21
- Interrupt 19 capture 21
- Quick boot 21
- Ta785g3 ta780g3 ta760g3 bios manual 21
- Chipset menu 22
- Southbridge configuration 22
- Ta785g3 ta780g3 ta760g3 bios manual 22
- This submenu allows you to configure the specific features of the chipset installed on your system this chipset manage bus speeds and access to system memory resources such as dram it also coordinates communications with the pci bus 22
- Ec configuration 23
- Hd audio azalia device this item allows you to control the hd audio device options enabled default auto disabled azalia clock gating options disabled default enabled 23
- Sb azalia audio configuration 23
- Ta785g3 ta780g3 ta760g3 bios manual 23
- Ta785g3 ta780g3 ta760g3 bios manual 24
- Internal graphics configuration 25
- Internal graphics mode this item allows you to select the memory mode used for internal graphics device options uma default disable 25
- Rs780 configuration 25
- Ta785g3 ta780g3 ta760g3 bios manual 25
- Ta785g3 ta780g3 ta760g3 bios manual 26
- Gen2 high speed mode options auto default disabled software initiated advertised rc link aspm options disabled default l0s l1 l0x l1 link width options auto default x1 x2 x4 x8 x16 slot power limit w options 75 default 0 255 nb sb port features 27
- Port 02 features 27
- Ta785g3 ta780g3 ta760g3 bios manual 27
- Onboard peripherals configuration 28
- Ta785g3 ta780g3 ta760g3 bios manual 28
- Ta785g3 ta780g3 ta760g3 bios manual 29
- Beware of that setting inappropriate values in items of this menu may cause system to malfunction 30
- Notice 30
- Overclock navigator 30
- Overclock navigator is designed for beginners in overclock field based on many test and experiments from biostar engineer team overclock navigator provides 3 default overclock configurations that are able to raise the system performance options normal default automate overclock manual overclock 30
- T series menu 30
- Ta785g3 ta780g3 ta760g3 bios manual 30
- This submenu allows you to change voltage and clock of various devices however we suggest you use the default setting changing the voltage and clock improperly may damage the device 30
- Auto overclock system 31
- Cautions 31
- Not every amd cpu performs the above overclock setting ideally the difference may vary with the installed cpu model 31
- Ta785g3 ta780g3 ta760g3 bios manual 31
- The overclock navigator provides 3 different engines helping you to overclock your system these engines will boost your system performance to different level options 31
- V12 tech engine this engine will make a best over clock performance 31
- V6 tech engine this engine will make a good over clock performance 31
- V8 tech engine this engine will make a better over clock performance 31
- Cpu configuration 32
- Cpu ht reference clock mhz 32
- Manual overclock system m o s 32
- Mos is designed for experienced overclock users it allows users to customize personal overclock setting 32
- Ta785g3 ta780g3 ta760g3 bios manual 32
- This item allows bios to select cpu over clock options 200mhz default 200mhz 600mhz 32
- This item allows you to save cpu configuration options auto default configure 1 7 32
- Core fid 33
- Cpu nb ov er voltage 33
- Cpu tuning 33
- Cpu vcore 33
- Custom p states 33
- Ta785g3 ta780g3 ta760g3 bios manual 33
- This item allows you to select cpu vcore control options auto default 0 50v 1 50v interval 0 5v 33
- This item allows you to select nb over voltage control options auto default 0 v 0 v 0 v 33
- This item allows you to select the ratio frequency of am2 cpu options x8 1600mhz x15 3000mhz differed by cpu 33
- This item tells bios whether to use the setup options below this to configure the p states or whether to configure the p states automatically options disabled default enabled 33
- Ta785g3 ta780g3 ta760g3 bios manual 34
- Clock control 35
- Ta785g3 ta780g3 ta760g3 bios manual 35
- Cpu nb ov er voltage 36
- Cpu vcore 36
- Gfx engine clock 36
- Gfx engine clock override 36
- Spread spectrum 36
- Ta785g3 ta780g3 ta760g3 bios manual 36
- This item allows bios to select onboard gpu over clock options 500 default 150 1000 36
- This item allows you to control spread spectrum function options disabled default enabled 36
- This item allows you to control the internal gfx engine clock override function options disabled default enabled 36
- This item allows you to select cpu vcore control options auto default 0 50v 1 50v interval 0 5v 36
- This item allows you to select nb over voltage control options auto default 0 50v 1 50v interval 0 5v 36
- Voltage configuration 36
- Chipset over voltage 37
- Dram timing configuration 37
- Ht ov er voltage 37
- Memclock value 37
- Memory clock mode 37
- Memory over voltage 37
- Ta785g3 ta780g3 ta760g3 bios manual 37
- This item allows you to control the memory clock options auto default manual limit 37
- This item allows you to select chipset voltage control options 1 2v default 1 7v 1 2v 1 7v 37
- This item allows you to select ddr over voltage control options 1 0v default 1 0v 2 0v interval 0 v 37
- This item allows you to select vtt voltage control options 1 4v default 1 8v 1 3v 1 7v 37
- This item allows you to set the memory clock options ddr3 800 default ddr3 1066 ddr3 1333 ddr3 1600 auto 37
- Ta785g3 ta780g3 ta760g3 bios manual 38
- Bank interleaving 39
- Bank interleaving is an advanced chipset technique used to improve memory performance memory interleaving increases bandwidth by allowing simultaneous access to more than one piece of memory options auto default disabled 39
- Channel interleaving 39
- Memory configuration 39
- Options auto default 39
- Ta785g3 ta780g3 ta760g3 bios manual 39
- This item allows you to control the ddr2 dual channel function options xor of address bits 20 16 6 default xor of address bits 20 16 9 address bits 6 address bits 12 disabled 39
- Trfc0 trfc1 trfc2 trfc3 39
- Ta785g3 ta780g3 ta760g3 bios manual 40
- Ecc configuration 41
- Ecc mode this item allows you to select the dram ecc mode options disabled default basic good super max user dram ecc enabled options disabled default enabled dram scrub redirect options disabled default enabled 4 bit ecc mode options disabled default enabled dram bg scrub data cache bg scrub l2 cache bg scrub l3 cache bg scrub options disabled default 40ns 80ns 160ns 320ns 640ns 1 8us 2 6us 5 2us 10 us 20 us 41 us 81 us 163 us 327 us 655 us 41
- Ta785g3 ta780g3 ta760g3 bios manual 41
- G p u phase control 42
- G p u phase mode 42
- Ta785g3 ta780g3 ta760g3 bios manual 42
- This item allows you to control g p u phase mode power saving technology options auto default off 42
- Integrated memory test 43
- Integrated memory test allows users to test memory module compatibilities without additional device or software 43
- Step 1 43
- Step 2 43
- Ta785g3 ta780g3 ta760g3 bios manual 43
- This item is disabled on default change it to enable to precede memory test 43
- When the process is done change the setting back from enabled to disabled to complete the test 43
- Abandon all changes made during the current session and exit setup 44
- Abandon all changes made during the current session and restore the previously saved values 44
- Discard changes 44
- Discard changes and exit 44
- Exit menu 44
- Load optimal defaults 44
- Save all configuration changes to cmos ram and exit setup 44
- Save changes and exit 44
- Ta785g3 ta780g3 ta760g3 bios manual 44
- This menu allows you to load the optimal default settings and save or discard the changes to the bios items 44
- This selection allows you to reload the bios when problem occurs during system booting sequence these configurations are factory settings optimized for this system 44
- Cmos backup function 45
- It allows users to save different cmos settings into bios rom and reload any saved cmos setting for customizing system configurations moreover users are able to save an ideal overclock setting during overclock operation there are 10 sets of record addresses in total and users are able to name the cmos data according to personal preference 45
- Security 45
- Ta785g3 ta780g3 ta760g3 bios manual 45
- This sub menu allows you to provide revise supervisor and user password 45
- Ta785g3 ta780g3 ta760g3 bios manual 46
Похожие устройства
- Biostar TA785G3 Версия 6.3 Инструкция
- Biostar TA785G3+ Версия 6.x Инструкция BIOS
- Biostar TA785G3+ Версия 6.x Инструкция
- Biostar TA785G3 HD Версия 5.x Инструкция BIOS
- Biostar TA785G3 HD Версия 5.x Инструкция
- Biostar A760G M2+ Версия 6.x Инструкция BIOS
- Biostar A760G M2+ Версия 6.x Инструкция
- Biostar A760GE Версия 6.x Инструкция BIOS
- Biostar A760GE Версия 6.x Инструкция
- Biostar A780LE Версия 6.x Инструкция BIOS
- Biostar A780LE Версия 6.x Инструкция
- Biostar A780L M2L+ Версия 6.x Инструкция BIOS
- Biostar A780L M2L+ Версия 6.x Инструкция
- Biostar A780L Версия 6.x Инструкция BIOS
- Biostar A780L Версия 6.x Инструкция
- Biostar A780LB Версия 6.2 Инструкция BIOS
- Biostar A780LB Версия 6.2 Инструкция
- Biostar TA760G M2+ Версия 6.x Инструкция BIOS
- Biostar TA760G M2+ Версия 6.x Инструкция
- Biostar TA790GX A2+ Версия 5.x Инструкция BIOS
