TA785G3/TA780G3/TA760G3 BIOS Manual
30
Auto OverClock System
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx.xx (C)Copyright 198 5-200x, American Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
T-Series Settings
=========== Automa te OverClock System ==== =======
============ Manua l OverClock System ===== =======
WARNING: Please Clear C MOS if system no display
after overcloc king.
OverClock Navigato r [Automate Ove rClock]
Auto OverClock Sys tem [V6-Tech Engi ne]
> G.P.U Phase Cont rol
Integrated Memory Test [Disabled]
CPU/HT Reference C lock (MHz) [200]
CPU Configuration [Auto]
> CPU Tuning
> Clock Control
> Voltage Configua tion
> DRAM Timing Conf iguration
> Memory Configura tion
Exit
Options
Normal
Automate OverClo ck
Manual OverClock
The Overclock Navigator provides 3 different engines helping you to overclock your
system. These engines will boost your system performance to different level.
Options:
V6 Tech Engine
This engine will make a good over-clock performance.
V8 Tech Engine
This engine will make a better over-clock performance.
V12 Tech Engine
This engine will make a best over-clock performance.
Cautions:
Not every AMD CPU performs the above overclock setting ideally; the difference may vary
with the installed CPU model.
