TA785G3/TA780G3/TA760G3 BIOS Manual
24
RS780 Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatre nds, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
RS780 Chipset Configuration
RS780 CIMX Version : 4.4.0
> PCI Express Configuration
Primary Video Controller [PCI-GFX0-GPP -IGFX]
NB Power Management Features [Auto]
> Internal Graphics Configuration
Internal Graphics Conf
Internal Graphics Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Internal Graphics Configuration
UMA Frame Buffer Size [Auto]
FB Location [Above 4G]
AMD 780 HD Audio [Enable]
Internal Graphics Mode [UMA]
Surround View [Auto]
Options
Disable
UMA
Internal Graphics Mode
This item allows you to select the memory mode used for internal graphics device.
Options: UMA (Default) / Disable
