TA785G3/TA780G3/TA760G3 BIOS Manual
4
Floppy A
Select the type of floppy disk drive installed in your system.
Options: 360K, 5.25 in / 1.2M, 5.25 in / 720K, 3.5 in / 1.44M, 3.5 in /
2.88M, 3.5 in / None
IDE Configuration
The BIOS will automatically detect the presence of IDE/SATA devices. There is a
sub-menu fo r each IDE/SAT A device. Select a device and press <Enter> to enter
the sub-menu of detailed options.
BIOS SETUP UTILITY
Main
vxx.xx (C)Copyright 198 5-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Scr een
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
While entering s etup,
BIOS auto detect s the
presence of IDE
devices. This di splays
the status of au to
detection of IDE
devices.
IDE Confuguration
> Primary IDE Slav e
> SATA 1 Device
Hard Disk Write Pr otect [Disabled]
IDE Detect Time Ou t (Sec) [35]
> SATA 2 Device
> SATA 3 Device
> SATA 4 Device
> Primary IDE Mast er
