TA785G3/TA780G3/TA760G3 BIOS Manual
29
6 T-Series Menu
This submenu allows you to change voltage and clock of various devices.
(However, we suggest you use the default setting. Changing the voltage and clock
improperly may damage the device.)
Notice
z Beware of that setting inappropriate values in items of this menu may cause
system to malfunction.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx.xx (C)Copyright 198 5-200x, American Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
T-Series Settings
=========== Automa te OverClock System ==== =======
============ Manua l OverClock System ===== =======
WARNING: Please Clear C MOS if system no display
after overcloc king.
OverClock Navigato r [Normal]
> G.P.U Phase Cont rol
Integrated Memory Test [Disabled]
Auto OverClock Sys tem [V6-Tech Engi ne]
CPU/HT Reference C lock (MHz) [200]
CPU Configuration [Auto]
> CPU Tuning
> Clock Control
> Voltage Configua tion
> DRAM Timing Conf iguration
> Memory Configura tion
Exit
Options
Normal
Automate OverClo ck
Manual OverClock
OverClock Navigator
OverClock .Navigator is designed for beginners in overclock field.
Based on many test and experiments from Biostar Engineer Team, OverClock
Navigator provides 3 default overclock configurations that are able to raise the
system performance.
Options: Normal (Default) / Automate OverClock / Manual OverClock
