TA785G3/TA780G3/TA760G3 BIOS Manual
22
SB Azalia Audio Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
HD Audio Azalia Device [Enabled]
Azalia Clock Gating [Disabled]
Options
Auto
Disabled
Enabled
HD Audio Azalia Device
This item allows you to control the HD audio device.
Options: Enabled (Default) / Auto / Disabled
Azalia Clock Gating
Options: Disabled (Default) / Enabled
EC Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
SureBoot Feature [Enabled]
SureBoot Timeout [4 Seconds]
Options
Disabled
Enabled
