![Biostar M7VIT Grand [17/85] Deutsch](/views2/1711926/page17/bg11.png)
14
Deutsch
Spezifikationen von M7VIT Grand
A. Har dware
CPU
Unterstützung für Sockel A.
Unterstützung für die AMD
®
Athlon/ Duron-Familie Prozessoren.
FSB mit 200/266/333/400 MHz.
Chipsatz
Northbridge: VIA KT600.
Southbridge: VIA VT8237.
Hauptspeicher
Unterstützung für 2 DDR Geräte.
Unterstützung für 200/266/333/400 MHz Hochgeschwindigkeit DDR Spreicher.
Die maximale Speichergröße ist 2GB.
Super I/O
Chip: Winbond W83697HF.
Steckplätze
Fünf 32-bit PCI-Bus-Slots.
Ein 8X AGP-Slot.
Ein CNR-Slot. (nur Typ B)
Onboard-IDE
Unterstützung für vier IDE Diskettenlaufwerke.
Unterstützung für PIO Modus 4, Bride Modus und Ultra DMA 33/66/100/133 Bus
Master Modus.
LAN
Chip: VIA VT6103
Unterstützung für 10 Mb/s und 100 Mb/s Auto-Negotiation.
Halb/Voll-Duplex.
Onboard AC’97 Sound Codec
Chip: CMI9739A.
Entspricht die Spezifikation von AC’97.
Unterstützung für 6-Kanal.
Onboard-Peripheriegeräte
a. Für Rückwand
2 serielle Schnittstellen.
1 parallele Schnittstelle. (SPP/EPP/ECP-Modus)
