17
CPU-Lüfter Headers: JCFAN1
Pin Belegung
1
Masse
2
+12V
1
3
FAN RPM Sensor
RPM: “Rounds per Minute”, deutsch: Umdrehungen pro Minute.
System -Lüfter Headers: JSFAN1
Pin Belegung
1
Masse
2
+12V
13
3
FAN RPM Sensor
DIMM-Modulen: DIMM1, DIMM2
DRAM-Zugriffszeit: 2.5V unbuffered / registered DDR PC1600/ 2100/ 2700/ 3200
Ty p erforderlich.
DRAM-Ty p: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM-Module (184-Pin)
※ CPU-FSB/Speichertakt Unterstützungsmatrix
CPU FSB\ Speichertakt DDR 266 DDR 333 DDR400
200 MHz
JA Nein Nein
266 MHz
JA JA JA
333 MHz
JA JA JA
400 MHz
JA JA JA
Gesamte Spei ch ergr öße von unb u ffered DI MMs
DIMM-Sockel
Standort
DIMM-Modulen
Speichergröße
(MB )
DIMM1
64MB/128MB/256MB/512MB/1GB
*1
DIMM2
64MB/128MB/256MB/512MB/1GB
*1
Maximal ist
2 GB
***Nur als Referenz***
