DAIKIN Building Air conditioning Control System (D-BACS) ED34-645B
696 Control
2.4 Various PC Boards
Besides the central control system and building control system of the previous page, you can enhance control
function by mounting various PC boards on indoor and outdoor units.
Adaptor for Wiring
The model of adaptor for wiring depends on the type of indoor unit.
Part Name Model No. Function
Adaptor for Wiring
KRP1B56, 57,
59, 61
KRP1C3
PC board when equipped with auxiliary electric heater or humidifier in the indoor unit.
