Front Panel Audio-out Header: JAUDIO1
This connector will allow user to connect with the front audio out put
headers on the PC case. It will disable the output on back panel audio
connectors.
1
2
13
14
JAUDIO1
Pin Assignment Pin Assignment
1 Mic in/center 2 Ground
3 Mic power/Bass 4 Audio power
5
Right line out/Speaker out
Right
6
Right line out/Speaker out
Right
7 Reserv ed 8 Key
9 Left line out/Speaker out Left 10 Left line out/Speaker out Left
11
Right line in/Rear speaker
Right
12
Right line in/Rear speaker
Right
13 Left line in/Rear speaker Left 14 Left line in/Rear speaker Left
CD-ROM Audio-in Connector: JCDIN1/JCDIN2
(JCDIN2 is optional.)
This connector allows user to connect the audio source from the variety
devices, like CD-ROM, DVD-ROM, PCI sound card, PCI TV turner card
etc..
Pin Assignment
1 Left channel input
2 Ground
3 Ground
1
JCDIN1/JCDIN2
4 Right channel input
Digital Audio-out Connector: JSPDIF_O UT (optional)
This connector will allow user to connect the PCI bracket SPDIF output
header.
Pin Assignment
1 +5V
2 SPDIF OUT
1
JSPDIF_OUT
3 Ground
