NF325-A7

1.5 LAYOUT OF VERSION 1.1

GP1

BIOS

JATXPWR1

Super I/O

BAT1

JKBMSV1

JAU DIO1

J CDIN1

JSPDIF_OUT

(optional)

JSATA5

JSATA4

JPANEL1

JUSBV3

JUSB1

JSFAN1

JCMOS1

JC I1

JCFAN1

DD R1

DDR2

JUSB2

JC OM2*

JCO M3* JC OM1

LA N

JC DIN2

(o pt io na l)

Codec

CNR

J SPDIF_IN

(optional)

JUSBV1

Note:

1. ● represents the 1

pin.

2. JCOM2 and JCOM3 are optional, and only one of them can be chosen.
