NF325-A7

1.4 COMPONENTS OF VERSION 1.0

GP1

BIOS

Super I/O

Codec

BAT 1

DDR1

DDR2

LAN

JATXPWR1~2: ATX power

connectors.

IDE1~2: Hard disk connectors.

JUSBV1: Power source for JUSB3.

JSFAN1: System fan connector.

JKBMSV1: Power source for JKBMS1.

JCMOS1: Clear CMOS Header.

Back panel connectors.

JCI1: Case open Header.

JAUDIO1: Audio out header.

JUSB1~2: Front USB headers.

AGP1: Accelerated Graphics Port slot.

JUSBV3: Power source for JUSB1~2.

JCDIN1: CD-ROM audio-in header

JSATA4~5: Serial ATA connectors.

JSPDIF_OUT: Digital audio out header

(optional).

FDD1: Floppy disk connector.

PCI1~5: Peripheral Component

Interconnect slots.

DDR1~2: DDR memory modules.

JPANEL1: Front panel connector.

JCFAN1: CPU f an connector
