![Biostar A68I-350 DELUXE Версия 6.x [30/45] French](/views2/1712337/page30/bg1e.png)
Motherboard Manual
28
French
Spécifications
Support Unité
Centrale
AMD E-350D (A68I-350 DELUXE/ A68I-350 DELUXE R2.0) / AMD C-60 (A68I-C60)
Jeu de puces AMD A68 FCH
Mémoire
Supporte mémoire DDR3 single canal 800/ 1066
Banc de mémoire 2 x DDR3 DIMM, Supporte max. jusqu’à une mémoire de 16 GB
Chaque module DIMM supporte module DDR3 non-ECC 512MB/ 1/ 2/ 4/ 8 GB
* Veuillez vous reporter à
www.biostar.com.tw pour la liste des soutien de la mémoire.
Stockage Connecteur 3 x SATA 6Gb/s, Supporte système indigène IDE & AHCI mode
Réseau local
Realtek RTL 8111F
10/ 100/ 1000 Mb/s auto négociation, capacité bidirectionnelle à l'alternat /
bidirectionnelle simultanée
Codec audio ALC662, Canaux 5.1, écoute audio de haute définition
USB
Port 2x USB 3.0 (2 sur les I/O arrières)
Port 6x USB 2.0 (2 sur les I/O arrières et 4 en interne)
Connecteur
d’extension
1x PCIe 2.0 x16 Fente (x4)
I/O arrirèes
1x PS/2 Clavier
1x PS/2 Souris
1x Port HDMI
1x Port VGA
1x port LAN
2x Port USB 2.0
2x Port USB 3.0
3x entrées audio
I/O en interne
3x Connecteur SATA 6.0Gb/s
2x embases USB 2.0 (chaque embase supporte 2 Ports USB 2.0)
1x 4-Broche de carte
1x 24-Broche de carte
1x Connecteur ventilateur unité centrale
1x Connecteur ventilateur système
1x Fiche panneau avant
1x Fiche audio avant
1x Fiche mémoire CMOS vide
1x Embase port imprimante
1x Embase port série
1x Connecteur sortie S/PDIF
